Arc Gouging Torches Product Catalog
Explore our comprehensive range of professional Arc Gouging Torches, designed for various industrial applications from light to heavy-duty operations. Our catalog includes models ranging from 500A to 3000A, supporting a wide variety of carbon electrode sizes for optimal performance.
JG-3 Series Arc Gouging Torches
| Order Code | Model | Current Rating | Round Carbon Electrodes | Flat Carbon Electrodes | Application Range |
|---|---|---|---|---|---|
| 816-305 | JG-3A | 800A | Ø6-Ø10mm | 4×12-5×20mm | Light duty operations |
| 534-888 | JG-3B | 1000A | Ø6-Ø12mm | 5×12-5×25mm | Medium duty operations |
| 464-739 | JG-3C | 1000A | Ø6-Ø12mm | 4×12-5×25mm | Medium duty operations |
| 759-356 | JG-3D | 1500A | Ø6-Ø12mm | 5×12-5×25mm | Heavy duty operations |
Arc Gouging Torches - 600 AMPS Series
| Order Code | Model | Current Rating | Round Electrodes | Flat Electrodes | Application Category |
|---|---|---|---|---|---|
| 245-213 | JG86-1 | 600A | Ø4-Ø10mm | 4×12-5×20mm | Light to medium duty |
| 798-892 | JG86-2 | 600A | Ø4-Ø10mm | 4×12-5×20mm | Light to medium duty |
| 271-779 | JG-2 | 600A | Ø4-Ø10mm | 4×12-5×20mm | Light to medium duty |
| 764-617 | FLA600 | 600A | Ø6-Ø12mm | 5×15-5×20mm | Medium duty operations |
Arc Gouging Torches - JG5 Series
| Order Code | Model | Current Rating | Round Carbon Electrodes | Flat Carbon Electrodes | Application Category |
|---|---|---|---|---|---|
| 784-627 | JG-5型 (800A) 1 | 800A | Ø5-Ø10mm | 5×12-5×20mm | Light to medium duty |
| 198-110 | JG-5型 (800A) 2 | 800A | Ø5-Ø10mm | 5×12-5×20mm | Light to medium duty |
| 269-114 | JG-5型 (1000A) | 1000A | Ø5-Ø12mm | 5×12-5×25mm | Medium duty |
| 468-250 | JG-5型 (1500A) | 1500A | Ø5-Ø13mm | 5×12-5×25mm | Heavy duty |
K-Series Arc Gouging Torches Specifications
| Order Code | Model | Current Rating | Pointed Carbons | Flat Carbons |
|---|---|---|---|---|
| 969-172 | K-3000 | 600A | 1/8"(3.2mm) to 3/8"(10mm) | 3/8"(10mm) to 5/8"(16mm) |
| 900-479 | K-4000-1 | 600A | 1/8"-1/4" (3.2-6.4mm) | 5/32"-3/8" (4-10mm) |
| 900-479 | K-4000-2 | 800A | 1/8"-3/8" (3.2-10mm) | 5/32"-7/16" (4-11mm) |
| 827-524 | K-4000-3 | 1000A | 1/4"-1/2" (6.4-13mm) | 1/4"-1/2" (6.4-13mm) |
| 503-159 | K-4000-4 | 1200A | 3/8"-5/8" (10-16mm) | 3/8"-1/2" (10-13mm) |
| 699-863 | K-3 | 600A | 1/8"(3.2mm) to 3/8"(10mm) | 3/8"(10mm) to 5/8"(16mm) |
| 039-628 | K-5 | 1250A | 5/32"(4.0mm) to 5/8"(16mm) | 3/8"(10mm) to 5/8"(16mm) |
K-3A Gouging Torch (General Purpose 600A Max)
| Order Code | Current Rating | Accepted Electrodes |
|---|---|---|
| 864-523 | 600A (Max) | 1/8"(3.2mm), 5/32"(4.0mm), 3/16"(4.8mm), 1/4"(6.4mm), 5/16"(7.9mm), 3/8"(9.5mm) |
ANGLE-ARC K4000 Series
| Order Code | Model | Current Rating | Round Electrodes | Flat Electrodes |
|---|---|---|---|---|
| 748-797 | ANGLE-ARC K4000-11 | 1000A | 5/32" (4.0mm) to 1/2" (12.7mm) | 3/8" (9.5mm) & 5/8" (15.9mm) |
| 690-591 | ANGLE-ARC K4000 | 1000A | 5/32" (4.0mm) to 1/2" (12.7mm) | 3/8" (9.5mm) & 5/8" (15.9mm) |
High-Capacity Arc Gouging Torches
| Order Code | Model | Current Rating |
|---|---|---|
| 524-873 | JG-8 | 2000A |
| 451-883 | JG-12 | 3000A |
Specialized Electrode System - Jointed and Blasting Carbon Electrodes
Electrode Type: Jointed and Blasting Carbon (条纹连接碳棒)
Size Range: 1/2" (12.7mm) to 1" (25mm)
Diameter Span: 12.3mm total range
Features: Enhanced connection system, optimized for material removal, handles maximum material thickness, industrial-specification carbons.
Arc Gouging Torches - Pure Copper ND Series
The ND Series represents a comprehensive range of professional electrode holders designed for various amperage requirements, from medium-duty 500A applications to heavy-duty 1000A industrial use.
| Order Code | Model | Current Rating | Electrode Range (Metric) | Electrode Range (Imperial) |
|---|---|---|---|---|
| 176-208 | ND500A | 500A | Ø3.2-Ø4.0mm | 1/8"-5/32" |
| 845-039 | ND600A | 600A | Ø3.2-Ø4.0mm | 1/8"-5/32" |
| 271-623 | ND800A | 800A | Ø3.2-Ø5.5mm | 1/8"-7/32" |
| 431-028 | ND1000A | 1000A | Ø3.2-Ø9.5mm | 1/8"-3/8" |
